These two slinging methods do not grip the loads completely and should be used only when the loads are easily stabilized or cannot slip out of the sling. Simple Choker Hitch (Fig-3) and Double and Choked (Fig-4) : The included angle of the sling should not exceed 90 degrees.
The lifting should not commence until a shackle is connected to the sling legs. Basket hitch (Fig-2 ):Ī basket hitch should only be used when the sling is passed through part of the load and the load is balanced on the sling. Single-leg sling: Vertical or straight lift (Fig-1) :Ī vertical or straight lift is only suitable for lifting a load that will be stable when suspended from a single lifting point. As the Sling-To-Load Angle decreases, the tension on the sling leg(s) increases. When selecting a sling, always consider the Sling-to-Load Angle and the tension that will be applied to the sling. This principle applies in a number of conditions, including when one sling is used to lift at an angle and when a basket hitch or multi-leg bridle sling is used. Slings with adequate capacity to handle the “scale” weight of the load have catastrophically failed because the Sling-to-Load Angle and increased tension were not taken into account. The Sling-to-Load Angle has a dramatic effect on sling Work Load Limits. The Sling-to-Load Angle is the angle formed between a horizontal line and the sling leg or body. As with the choker hitch, more than one sling may be necessary to help ensure load control. The sling cradles the load while both eyes are attached overhead. One end is on the hook, while the other end is attached directly to the load. The Choke Point should always be on the sling body, not on the sling eye, fitting, base of the eye or fitting, splice or tag.
#Crane rigging formulas full#
For full contact use a Double Wrap Choke Hitch.
A choker hitch will never provide full 360 degree contact. Load control is limited with only one sling rigged in a choker hitch. Sling passes through one end around the load, while the other end is placed on the hook. A trained, qualified and knowledgeable user must determine the most appropriate method of rigging to help ensure load control and a safe lift. Slings must be securely attached to the load and rigged in a manner to provide for load control to prevent slipping, sliding and/or loss of the load. The synthetic choker hitch work Load Limit is a maximum of 80% of the vertical hitch work Load Limit. Slings have the largest work Load Limit when used in a basket hitch.The vertical hitch Work Load Limit is 50% of the basket hitch.
Most slings can be used in all three sling hitches, but some slings are designed for use in only one hitch. Slings carry their loads in one of three primary sling hitches.
